Features & Specif ications
|
INDEX TYPE
|
SO-5-5
|
SO-5-12
|
SO-5-15
|
SO-5-24
|
|
DC VOLTAGE
|
±10%
|
±10%
|
±10%
|
±10%
|
|
VOLTAGE TOLERANCE
|
±2%
|
±2%
|
±2%
|
±2%
|
|
RATED CURRENT
|
1A
|
0.42A
|
0.33A
|
0.23A
|
|
RIPPLE&NOISE (MAX.)
|
50mV
|
150mV
|
150mV
|
240mV
|
|
LINE REGULATION
|
±1%
|
±1%
|
±1%
|
±1%
|
|
LOAD REGULATION
|
±3%
|
±3%
|
±3%
|
±3%
|
|
RATED POWER
|
5W
|
5W
|
5W
|
5W
|
|
EFFICIENCY
|
65%
|
65%
|
67%
|
67%
|
|
VOLTAGE RANGE
|
110VAC-260VAC 47-63HZ
|
|
AC CURRENT
|
0.05A/220VAC
|
|
INRUSH CURRENT (MAX.)
|
cold inrushed currentt 25A/115V 45A/230VAC
|
|
OVERLOAD PROTECTION
|
105-150% type ：OUTPUT CUTOUT auto recovery
|
|
OVERVOLTAGE PROTECTION
|
115-135% type
|
|
SETUP.RISE,HOLD TIME
|
150ms 20ms 80ms
|
|
WITHSTAND VOLTAGE
|
I/P-O/P:3KVAC,1 MINUTE
|
|
WORKING TEMP.HUMIDITY
|
0-50℃@100%,-10℃@80%,60℃@60%,20%-90%RH
|
|
DIMENSION
|
57X47X21mm
|
|
WEIGHT
|
40g
|
|
SAFETY STANDARDS
|
To meet UL 1950
|
|
EMC
|
EN60950
|
Note:
1.All parameters NOT specially mentioned are measured at 230VAC input ,rated load and 25 of ambient temperature.
2.Tolerance:includes set up tolerance, line regulation and load regulation
3.Ripple&noise are measured at 20MHZ of bandwidth by using a 12 twisted pair-wire terminated with a 0.1uf&47uf parallel capacitor.
4.line regulation :min&max voltage of the rated load.
5.load regulation: load from 0 to 100%.
