Special Feature
Maximum continuous power 75 Watts
Surge capacity (peak power) 150 Watts
Maximum efficiency approx. 90%
Input voltage range 10-15V DC (12VDC)
Under voltage shutdown activation 10.0Volts
Over voltage shutdown activation 15.0 Volts
Wave form modified sine wave
Output AC voltage can be customer-made according to different countries 220VAC/240VAC/110VAC
Overload protection
Cigarette lighter plug
Thermal protection:65±5 degrees Celsius
The parameter you are reading now is based on DC 12V input
Measurement: 115×59×37 (mm)
Weight:0.15kgs
